CVT10-M

NovaStar CVT-10-M

 Inputs:

• 2x optical ports with bandwidth up to 10 Gbit/s


Outputs:

• Gigabit Ethernet ports, bandwidth up to 1 Gbit/s
• 1x USB-B

Efficient Long-distance Transmission:

• CVT10-M: Transmits up to 10 individual 1 Gb signals over a distance of up to 300 m.
• CVT10-S (single-mode): Transmission over a maximum distance of 10 km.

Signal Combination: All 10 Ethernet signals are transmitted via a single optical cable, simplifying management and installation.

Flexible installation:

• Compatible with 19-inch racks and 1U enclosures.
• A complete installation kit is included.

Compatibility with Processors: Can be directly connected to processors with optical output, such as VX1000, MCTRL660PRO, and MCTRL4K.

Wide Range of Equipment and Accessories: Comes with a power cable, USB cable, 2x 10G SFP (LC) modules, an installation kit, and an assembly diagram.

High Performance and Ports:

• 2x optical ports: With interchangeable modules during operation, each with bandwidth up to 10 Gbit/s.
• 10x Gigabit Ethernet ports: Bandwidth of each up to 1 Gbit/s.
• 1x USB-B control port for easy operation.
